Name: FL-5.2W

Model Number: FL-5.2W

Features:
1)Split design,ultra-low noise
2)Wall mounted,save space
3)Panasonic compressor, long service life
4)Programmable PLC controller
5)Brand electronic spare parts,stable quality
6)RS485(optional)

ModelFL-5.2W
Cooling capacity5.2KW
Suitable area10-15㎡
Air volume980m³/h
Temperature/humidity control range16-28℃±1℃；RH45-75%±5%
Refrigerant gasR22/R410A/R407C
Heating typeElectrical heater
Humidification typeAtomization/Wet film humidification
Water intake method Automatic or manual
Humidity capacity3kg/h
Voltage of indoor machine220V/50HZ
Voltage of outdoor machine
RelaySchneider
AC contactor
Control systemProgrammable PLC with LCD touch screen
Power input4.3kw
Indoor machine dimension(L*W*H)650*350*750mm
Outdoor machine dimension(L*W*H)950*350*840mm
Indoor machine N.W.86kg
Outdoor machine N.W.68kg
