Name: Thermostat humidistat Series FL-14.9C

Model Number: FL-14.9C

Features:
1)Split design,ultra-low noise
2)Ceiling mounted,save space
3)Panasonic compressor, long service life
4)Programmable PLC controller
5)Brand electronic spare parts,stable quality
6)RS485(optional)

ModelFL-14.9C
Cooling capacity14.9KW
Suitable area35-45㎡
Air volume2500m³/h
Temperature/humidity control range16-28℃±1℃；RH45-75%±5%
Refrigerant gasR22/R410A/R407C
Heating typeElectrical heater
Humidification typeAtomization/Wet film humidification
Water intake method Automatic or manual
Humidity capacity3kg/h
Voltage of indoor machine220V/50HZ
Voltage of outdoor machine
RelaySchneider
AC contactor
Control systemProgrammable PLC with LCD touch screen
Power input11.9kw
Indoor machine dimension(L*W*H)1456*652*361mm
Outdoor machine dimension(L*W*H)950*350*1240mm
Indoor machine N.W.95KG
Outdoor machine N.W.130KG
